This high-efficiency 415W-435W semiconductor photovoltaic module is designed for optimal energy generation with up to 22.3% efficiency. Utilizing TOPCON technology with 182*91mm cell size, this module integrates advanced PID resistance and enhanced mechanical load durability, capable of withstanding front loads up to 5400Pa and rear loads up to 2400Pa. It also boasts excellent performance in low-light conditions, making it ideal for environments with varying weather patterns. The product is built with an anodized frame, IP68-rated junction box, and customizable cable options, ensuring durability and flexibility in installation.
| Mechanical specifications | |||||
| Cell Type | TOPCON 182*91mm | OPERATING PARAMETER | |||
| No.OfCells | 108 M(6*18) | Max.System Voltage | 1500V/DC | ||
| Junction Box | IP68.3 diodes | Operation Temperature | -40℃-85℃ | ||
| Frame | Anodized frame | Max.Snow Load(Front) | 5400Pa | ||
| Weight | 20.5Kg±3% | Max.Wind Load(Front) | 3600Pa | ||
| Dimension | 1722*1134*30mm | NOCT | 45±2℃ | ||
| Cable | 4mm².350mm inlength,can be customized | Gustomzoble | All black,Double gloss | ||
| Glass | Single glass,3.2mm high tansmission.antireflection coating | ||||
| ElectricalCharacteristics | |||||
| Module Type | 108M | ||||
| STC NOCT STC NOCT STC NOCT STC NOCT STC NOCT | |||||
| Maximum Power(Pmax) | 415W 312W 420W 316W 425W 320W 430W 324W 435W 328W | ||||
| Maximum Power Voltoge (Vmp) | 31.84V 29.78V 32.04V 29.97V 32.24V 30.16V 32.44V 30.35V 32.64V 30.54V | ||||
| Maximum Power Curent (imp) | 13.04V 10.48V 13.11V 10.54V 13.18V 10.61V 13.26V 10.67V 13.33V 10.74V | ||||
| Open-circuit Voltage(Voc) | 37.95A 36.06A 38.15A 36.24A 38.35A 36.42A 38.55A 38.60A 38.75A 36.78A | ||||
| Short-circuit Current (lsc) | 13.74A 11.09A 13.80A 11.14A 13.86A 11.19A 13.92A 11.24A 13.98A 11.29A | ||||
| 79.63% 79.79% 79.94% 80.16% 80.32% | |||||
| Module Efficiency STC(%) | 21.25% 21.51% 21.76% 22.02% 22.28% | ||||
| Temperature Characteristcs | ||
| NMOT | 45+2℃ | |
| Temp Coefficient of ISC | +0.05%/C | |
| Temp Coefficient of VOC | -0.28%℃ | |
| Temp Coefficient ofPmax | -0.34%℃ | |
| Modules/Pallet | 36 Pieces | |
| Modules/40'Container | 936Pieces | |
| Pockaging Desciption | 26 Pallets.Total=(36+36)x13=936 Pieces | |
Perfect for large-scale commercial solar power plants and residential installations, this photovoltaic module excels in high-efficiency energy generation and is designed to handle extreme environmental conditions, including wind and snow. With superior weak light performance and lower operating temperatures, it ensures higher energy output in diverse climatic conditions.
