560W 182 N-TopCon Monofacial Module High-Performance Solar Panels for All Weather Conditions
Product Description:
The 182 N-TopCon Monofacial Module offers a power range from 560W to 580W, providing outstanding efficiency of up to 22.45%. This module is equipped with 144pcs of 182mm N-TopCon Mono Cells arranged in a 6×24 configuration. It is designed with high transparency tempered glass and an anodized aluminum alloy frame, ensuring long-term durability and high-performance output. The module's advanced structure and design make it highly efficient even in low-light conditions.
| Electrical Performance Parameters |STC | |||||||
| Model Type | 560C(HPM) 565CHPM) 570C(HPM) 575C(HPM) 580C(HPM) 72(182) 72(182) 72(182) 72(182) 72(182 |
||||||
| NominalMax.Power Pmax(W) | 560 565 570 575 580 | ||||||
| Max.Power Voltage Vmp(V) | 41.92 42.08 42.23 42.38 42.53 | ||||||
| Max.Power Current Imp(A) | 13.36 13.43 13.50 13.57 13.64 | ||||||
| Open CircuitVoltage Voc(V) | 50.42 50.56 50.70 50.84 50.98 | ||||||
| Short Circuit Current Iso(A) | 14.11 14.19 14.27 14.35 14.43 | ||||||
| Module Efficiency (%) | 21.68 21.87 22.07 22.26 22.45 | ||||||
| Power Output Tolerance (W) | 0~+5W | ||||||
| ·STC:Irradiance 1000W/m², Cel Temperature 25℃,Air Mass AM1.5. 'Power measurement tolerance ±3%. |
|||||||
| Electrical Performance Parameters |NMOT | |||||||
| ModelType | 560C(HPM) 72(182) |
565C{HPM) 72(182) |
570C(HPM) 72(182) |
575C(HPM) 72(182) |
580C(HPM) 72(182) |
||
| Nominal Max.Power | Pmax(W) | 421 | 425 | 429 | 433 | 437 | |
| Max.Power Voltage | Vmp(V) | 39.42 | 39.58 | 39.73 | 39.84 | 39.95 | |
| Max.Power Current | Imp(A) | 10.68 | 10.74 | 10.80 | 10.87 | 10.94 | |
| Open Circuit Voltage | Voc(V) | 47.88 | 48.02 | 48.16 | 48.29 | 48.42 | |
| Short Circuit Current | Isc(A) | 11.39 | 11.45 | 11.51 | 11.58 | 11.64 | |
| NMOT:Irradiance 800W/m²,CeI Temperature 20℃,Wind Speed 1m/s. *Power measurement tolerance ±3%. |
|||||||
| Structure Performance | |||||||
| Solar Cell Type | 182mm N-TopConMono Cell(Half Ceill) | ||||||
| Solar Cell Arrangement | 144pcs(6×24) | ||||||
| Module Dimension | 2278×1134×35mm/30mm | ||||||
| Weight | 28.0kg(35mm)/26.3kg(30mm) | ||||||
| Front Glass | 3.2mm,highly transparent tempered glass with antrreflective coating |
||||||
| Back Sheet | White | ||||||
| Frame | Anodized Aluminum Alloy | ||||||
| Junction Box | IP68 rated | ||||||
| Diode Quantity | 3 pcs | ||||||
| Front side/Rear side | 5400pa/2400pa | ||||||
| Connector | MC4 Compatible | ||||||
| Per Pallet | 31pcs(35mm)/36pcs(30mm) | ||||||
| Per Container(40'HQ) | 620pcs(35mm)/720pcs(30mm) | ||||||
| Temperature Characteristics | |||||||
| Nominal Module Operating Temperature | 44±2℃ | ||||||
| Temperature Coefficient (Isc) | +0.043% | ||||||
| Temperature Coefficient (Voc) | -0.25% | ||||||
| Temperature Coefficient (Pmax) | -0.30% | ||||||
| Maximum Parameters | |||||||
| Working Temperature | 40~+85℃ | ||||||
| MaximumSystem Voltage | 1500V DC | ||||||
| Nominal Maximum Fuse Current | 25A | ||||||
Application:
This high-performance solar module is ideal for large-scale commercial and industrial solar power installations. It is particularly well-suited for regions with variable weather conditions due to its superior efficiency and temperature characteristics. The module's robust design and construction allow it to withstand harsh environmental conditions, making it a reliable choice for maximizing power generation.
