515W 22.32% Maximum Efficiency Monocrystalline Silicon Panels for Low-Light Energy Production
Product Description:
The 182 N-TopCon Bifacial Module (515W-530W) is a top-tier solar panel that boasts a power output range of 515W to 530W, with a power output tolerance of 0W to +5W. This module is designed for high efficiency, with a maximum efficiency of 22.32%, ensuring excellent energy production even under low-light conditions. It utilizes advanced N-TopCon Mono Cell technology with 132 cells arranged in a 6x22 layout, offering enhanced durability and performance.
The panel's structure features a robust anodized aluminum alloy frame, highly transparent tempered glass with anti-reflective coating, and an IP68-rated junction box for superior weather resistance. This module is compatible with MC4 connectors, making it versatile for various installation configurations.
| Electrical Performance Parameters |STC | |||||||
| Mode Type | 515C/HBD 66(182) |
520COHBD 66(182) |
525C(HBD) 66(182 |
530C(HBD) 66(182 |
|||
| Nominal Max.Power | Pmax(W) | 515 | 520 | 525 | 530 | ||
| Max.Power Voltage | Vmp(V) | 3,850 | 38.70 | 38.89 | 39.09 | ||
| Max.Power Current | Imp(A) | 13.38 | 13.44 | 13.50 | 13.56 | ||
| Open Circuit Voltage | Voc(V | 46.17 | 46.37 | 46.57 | 46.77 | ||
| Short Circuit Current | lsc(A) | 14.31 | 14.37 | 14.43 | 14.49 | ||
| Module Eficiency | (%) | 21.69 | 21.90 | 22.11 | 22.32 | ||
| Power Output Tolerance | (W) | 0~+5W | |||||
| ·STC:Irradiance 1000W/m²,Cell Temperature 25℃,Air Mass AM1.5. 'Power measurement tolerance ±3%. |
|||||||
| Electrical Performance Parameters |NMOT | |||||||
| Model Type | 515C(HBD) 66(182) |
520C(HBD) 66(182) |
525C(HBD) 66(182) |
530C(HBD) 66(182) |
|||
| Nominal Max.Power | Pmax(W) | 386 | 390 | 394 | 398 | ||
| Max.Power Voltage | Vmp(V) | 36.22 | 36.39 | 36.55 | 36.72 | ||
| Max.Power Current | Imp(A) | 10.66 | 10.72 | 10.78 | 10.84 | ||
| Open Circult Voltage | Voc(V) | 43.62 | 43.81 | 44.00 | 44.19 | ||
| Short Circuit Current | lsc(A) | 11.58 | 11.63 | 11.68 | 11.73 | ||
| ‘NMOT:Iradiance 800W/m²,Cell Temperature 20℃,Wind Speed 1m/s. *Power measurement tolerance ±3%. |
|||||||
| Structure Performance | ||||||||
| Solar Cell Type | 182mm N-TopCon Mono Cell (Half Cell) | |||||||
| Solar Cell Arrangement | 132pcs(6x22) | |||||||
| Module Dimension | 2094×1134×35mm/30mm | |||||||
| Weight | 29.6kg(35mm)/28.4kg(30mm) | |||||||
| Front Glass | 2.0mm,highly transparent tempered glass with anti-reflective coating |
|||||||
| Frame | Anodized Aluminum Alloy | |||||||
| Junction Box | IP68 rated | |||||||
| Cable | 4mm²,portrait 400mm2(t0)0mm(-,)landscape m0( m(-) Length can be customized |
|||||||
| Diode Quantity | 3 pcs | |||||||
| Front side/Rear side | 5400pa/2400pa | |||||||
| Connector | MC4 Compatible | |||||||
| Per Pallet | 31pcs(35mm)/36pcs(30mm) | |||||||
| Per Container(40'HQ) | 682pcs(35mm)/792pcs(30mm) | |||||||
| Temperature Characteristics | ||||||||
| Nominal Module Operating Temperature | 44±2℃ | |||||||
| Temperature Coefficient (Isc) | +0.043% | |||||||
| Temperature Coefficient (Voc) | -0.25% | |||||||
| Temperature Coefficient (Pmax) | -0.30% | |||||||
| Maximum Parameters | ||||||||
| Working Temperature | -40~+85℃ | |||||||
| Maximum System Voltage | 1500V DC | |||||||
| Nominal Maximum Fuse Current | 30A | |||||||
Application:
This module is ideal for large-scale commercial and utility solar power installations where maximum efficiency and reliability are paramount. Its bifacial design also makes it suitable for installations where reflected light from surfaces like rooftops or the ground can contribute to increased energy generation.
