The ALPHA Series Inverter/Charger is designed to provide reliable energy conversion and storage solutions for both residential and small commercial applications. With a power output range from 1.5KVA to 3KVA, this series is perfect for supporting essential home or office loads during power outages or integrating with solar power systems. The inverters feature a pure sine wave output, ensuring the safe operation of sensitive electronics and appliances. The integrated lithium iron battery with capacities ranging from 1.28KWh to 5.12KWh ensures long-lasting energy storage and reliable power supply. Built with advanced protection features, such as overcharge, overdischarge, overcurrent, and short-circuit protection, the ALPHA series delivers optimal performance in various environments.
| MODEL SPECIFICATION |
ALPHA1.5KVA/1.28KWH | ALPHA3KVA/2.56KWH | ALPHA3KVA/5.12KWH |
| Inverter /Charger | |||
| Inverter Type | 1.5KVA/12V | 3KVA/24V | 3KVA/24V |
| Rated Output Power | 1.5KW | 2.7KW | 2.7KW |
| Output Voltage Waveform | Pure Sine Wave | Pure Sine Wave | Pure Sine Wave |
| Output Voltage | 230VAC 50HZ | 230VAC 50HZ | 230VAC50HZ |
| Charging Current(Utility and solar together) | 80AMax. | 80AMax. | 80AMax. |
| ACInput | |||
| Nominal Input Voltage | 230Vac | ||
| Voltage Range | 170-280Vac(UPS),90-280Vac(Appliances) | ||
| Nominal Input Frequency | 50HZ/60HZ(Auto detection) | ||
| AC ChargingCurrent | 60AMax. | 60AMax. | 60AMax. |
| Solar Input | |||
| Nominal PV Voltage | 240Vdc | 240Vdc | 240Vdc |
| PV Array MPPT Voltage Range | 30Vdc~80Vdc | 30Vdc~350Vdc | 30Vdc~350Vdc |
| SolarCharging Current | 60AMax. | 60AMax. | 80AMax. |
| LithiumIronBattery | |||
| Capacity | 1280Wh | 2560Wh | 5120Wh |
| Nominal BatteryVoltage | 12.8Vdc | 25.6Vdc | 25.6Vdc |
| Typical Capacity | 100Ah | 100Ah | 200Ah |
| Max.Charge Current | 50A | 50A | 50A |
| Max.Discharge Current | 100A | 100A | 100A |
| Operation Temperature | -10℃~+50℃ | ||
| Protection | |||
| Protection | Overcharge/Overdischarge/Overcurrent/Overtemperature/Shortcircuit protection | ||
| Ambient | |||
| Noise(dB) | <40dB(1meter) | ||
| Working Temperature | -10℃~+50℃ | ||
| Humidity | 0~95%(no condensation) | ||
| Sea Level(m) | ≤1500 | ||
| Dimension | |||
| LXWXH(products size) | L450*W213*H636mm | L450*W279*H731mm | L873*W480*H279mm |
| L×WXH (package size) | L721*W535*H298mm | L816*W535*H364mm | L941*W555*H354mm |
This series is ideal for applications such as:
