3000W-5500W Energy Solutions for Residential and Commercial LSOTH Hybrid Inverters
Product Description
The LSOTH series hybrid inverters offer advanced energy solutions for residential and commercial applications. These inverters integrate pure sine wave output with a built-in MPPT solar charge controller, ensuring efficient power management. With selectable charging currents and configurable AC/Solar input priority via the LCD settings, the inverter can be customized to suit different energy setups. Featuring cold start functionality and compatibility with mains voltage or generator power, the LSOTH series ensures reliable and flexible power delivery even in challenging environments. The smart battery charger optimizes battery performance, and the system supports parallel operation with up to 6 units, providing scalability for larger installations.
| Product Model | LSOTH3KTL-P2 | LSOTH3K⁵TLP2 | LS⁰TH5KTLP2 | LSOTH⁵K5TLP2 | |
| Input | nput sources | L+N+PE | |||
| Batod input votage | 208/220/230/240VAC | ||||
| Voftage range | 154-264VAC±3V(APP Mode)185-264VAC±3V(UPS Mode | ||||
| Freguongy | 50Hz/60Hz(Auto Adaptive) | ||||
| Output | Ratedpower | 3000W | 3500W | 5000W | 5500W |
| Output voltage | 208/220/230/240VAC±5% | ||||
| Outputfrequency | 50/60Hz±0.1% | ||||
| Waveform | Pure Sine Wave | ||||
| Transfertime(adjustable | Computers(UPS Mode)10ms,Appliance(APP Mode)20ms | ||||
| Peak power | 6000VA | 7000VA | 10000VA | 11000VA | |
| Over load ablity | Battery Mode:1min@102%~110%Load,10s@110%~130%Load,3s@130%~150%Load,200ms@>150%Load | ||||
| Peak efficiency (battery Mode) | >94% | >94% | >94% | >94% | |
| Batteny | Batteryvotage | 24Vdc | 24Vdo | 48Vdo | 48Vdo |
| Constant charging vofage | 28.2Vdc | 28.2Vdc | 56.4Vdo | 56.4Vdc | |
| Hoate chargingvoltage | 27Vdo | 27Vdo | 54Vdo | 54Vdo | |
| Charges | PV charging mode | MPPT | MPPT | MPPT | MPPT |
| Max PV input power | 1500W | 1500W | 5500W | 5500W | |
| MPPT tracking range | 30-145Vdo | 30-145Vde | 120-500Vdc | 120-500Vdc | |
| Best voltage | 30-115V | 30-115V | 300-400V | 300-400V | |
| Max PV input vohage | 150Vdo | 145Vdo | 500Vda | 500Vdo | |
| Max PVcharging current | 60A | 60A | 100A | 100A | |
| Max AC chargingcurren | 60A | 60A | 100A | 100A | |
| Max charging current | 120A | 120A | 100A | 100A | |
| Display | LCD display | Display running mode/loads/input/output etc | |||
| Interface | RS232 | 5Pin/pitch2.0mm,baud rate 2400 | |||
| Communication port | 2×5Pin/pitch2.54mm,Lithlum latteryBMS communication card,wificard,drycontact | ||||
| Parallel connect interface | Wthoutparallel connect Withparallel(optional | ||||
| Enwionmen | Operating temperature | 0-40℃ | |||
| Humidity | 20%-95%(non-condensing) | ||||
| Storagetemperature | -15-60℃ | ||||
| Atitude | AItiude not over 1000m,deratingover1000m,max4000m,refer to IEC62040 | ||||
| Noise | ≤50db | ||||
| Dimension | Net weight | 8.44kg | |||
| Gross weight | 9.79kg | ||||
| Product size | 477*318*123mm | ||||
| Package size | 552*385*193mm | ||||
| 1:The paralel addition ot inverters equres the adltion of accesorles and paralel boards.For more intormatlon.please contact the sales manager Remarks:Specifications aresubject to change without notice;Special voltage and powerequirements can be customized designed |
|||||
Application
The LSOTH series hybrid inverters are ideal for homes, small businesses, and commercial operations that require a combination of solar and utility grid power. These inverters offer excellent performance in areas with frequent power outages, supporting backup power and solar energy integration. With the option for parallel connection, the LSOTH series is suited for larger systems requiring high power output and efficient energy management.
