Intelligent Battery Management for Various Battery Types Hybrid Inverters
This high-efficiency inverter series is designed for various solar energy systems, providing stable power conversion from DC to AC with a pure sine wave output. Available in multiple models, it supports input voltages ranging from 154V to 275V AC and offers output powers from 5kW to 10kW, making it adaptable to different energy demands. Its advanced MPPT solar charge controller ensures efficient solar power utilization, while the intelligent battery management system supports a variety of battery types, including lead-acid, gel, and lithium. With dual-frequency (50/60Hz) output and robust AVR function, this inverter series ensures stable power delivery even under fluctuating grid conditions. Ideal for residential and small commercial solar installations, it provides maximum energy efficiency and protection for your power systems.
| Mag | JE6348 AH8 | E04AA | Je100348AMB | 1240AW | JE1012AP5 | E1512/24 AP5 | JE2024AMB | JE3024/48 AM8 | Je502/48 AM6 |
| AC Input voltage | 220VAC(standard) | 220VAC(standard) | |||||||
| nput voltage range | 154-264VAC±3V(Nor Model).185-264VAC±3V(UPS Model) 175-285VAC±3V(AVRType) | 154-275VAC±5V(Nor Model) | 154-264VAC±3V(Nor Model) 185-264VAC±3V(NorModel) 175-285VAC±3V(AVRType) | ||||||
| nput frequency | 50/60HZ±5% | 50/60HZ±5% | |||||||
| Output power | 6300VA 5000W | 8000VA 6400W | 10000VA 8000W | 12500VA 10000W | 1000VA 800W | 1500VA 1200W | 2000VA 1600W | 2000VA 2400W | 5000VA 4000W |
| ACmodel outout Voltage | The output voltage under the mains is the same as the input voltage(with AVR function 220V±10%) | The output voltage under the mains is the sameas the input voltage(with AVRfunction V10%) | |||||||
| Battery model outputfrequency | The output frequency under the mains isthe same as the input frequency | The oulputfrequengyunder the mains is the same as the input frequengy | |||||||
| Battery model output voltage | 220VAC±10% | 220VAC±3% | |||||||
| Battery model output frequency | 50HZ OR60HZ±1% | 50HZ OR 60HZ±1% | |||||||
| Battery model output wave | Pure sine wave | Pure sine wave | |||||||
| Battery type | Extermal lead-acid battery.Gel battery walerballeryor Lithlum ballery | Externallead-acidbattery,Gelbattery. water battery orLithlum battery | |||||||
| Battery voltage | 48VDC | 12VDC 12/24VDC 27/484VDC | |||||||
| Batlery charging voltage | 54VDC | 13.75VDC 13.75/27VDC | 27/54VDC | ||||||
| Maximum PVarray power | 6400w | 12V:800W 24V:1600W | 24V:1600W 48V:3200W | ||||||
| Solar input voltage range | 4BV:MPPT 60V-150VDC | 12V.PWM 15V-50VDC 24V.PWM 30V-105VDO | 24V MPPT 30V-150VDC 48V MPPT 60V-150VDC | ||||||
| MaximumPV Display Open Circuit Voltage | 150VDC | 12V:PWM 50VDC 24V;PWM 105VDC 150V | |||||||
| Maximum solar chargingcurren | 120A | 60A | |||||||
| MaximumAC Charge Current | 29A 38A | 48A | 60A | 19A 29A | 19A | 29A/15A | 48A/24A | ||
| Battery charging voltage range | 154-280VAC | 154-275VAC±5V | |||||||
| Transfor timo | ≤10ms(UPSy≤20ms(INV) | ≤10ms | ≤10ms(UPS)≤20ms(INV) | ||||||
| oad peak ratlo | MAX)3:1 | (MAX)3:1 | |||||||
This inverter series is perfect for solar energy storage systems in residential and commercial applications. It ensures seamless power conversion for off-grid and hybrid energy systems, making it suitable for homes, small businesses, and rural areas with inconsistent grid power. Its versatility in battery type support and wide voltage input range makes it an excellent choice for a variety of energy setups, including solar-powered irrigation systems, emergency power supplies, and backup energy storage.
