This upgraded multi-functional inverter/charger combines the features of an inverter, solar charger, and AC charger to ensure an uninterrupted power supply, all within a compact, portable design. With Bluetooth support for mobile monitoring, the detachable LCD display module allows user-friendly configuration of settings such as battery charging current, AC/solar priority, and input voltage thresholds for different applications.
| Rated Power 3500VA/3500W 5500VA/5500W | ||||||||
| INPUT | ||||||||
| Voltage | 230VAC | |||||||
| Selectable Voltage Range | 170-280 VAC(For Personal Computers); 90-280 VAC(For Home Appliances) |
|||||||
| Frequency Range | 50 Hz/60 Hz(Auto sensing) | |||||||
| OUTPUT | ||||||||
| AC Voltage Regulation | 230VAC±5% | |||||||
| (Batt.Mode) | ||||||||
| Peak Power | 7000VA | 11000VA | ||||||
| Efficiency(Peak) 93% | ||||||||
| Transter time | 10 ms(For Personal Computers); 20 ms(For Home Appliances) |
|||||||
| Waveform | Pure sine wave | ||||||
| BATTERY | |||||||
| Battery Voltage | 24VDC | 48VDC | |||||
| Floating Charge Voltage | 27VDC | 54VDC | |||||
| Overcharge Protection | 33VDC | 60VDC | |||||
| SOLAR CHARGER &AC CHARGER | ||||||||
| Max.PV Array Open Circuit Voltage | 500VDC 500VDC | |||||||
| Max.PV Array Power | 4000W 6000W | |||||||
| MPPT Range @operating Voltage | 120-450VDC 120-450VDC | |||||||
| Max.Solar Charge Current | 80A 80A | |||||||
| Max.AC Charge Current | 60A 60A | |||||||
| Max.Charge Current | 100A 100A | |||||||
| PHYSICAL | ||||||||
| Dimension,,D*W*H(mm) | 130*300*440 | |||||||
| Net weight (kg) | 9 | 10 | ||||||
| Communication Interface USB/RS232/RS485/BLUETOOTH/DRY-CONTACT | ||||||||
| Optional function | WIFI/4G | |||||||
| ENVIRONMENT | ||||||||
| Humidity 5%to 95%Relative Humidity (Non-condensing) | ||||||||
| Operating Temperature -10℃-50℃ | ||||||||
| Storage Temperature -15℃-60℃ | ||||||||
| Note:can be customized according to customer requirements | ||||||||
Ideal for residential and small commercial energy storage systems, this inverter can be used in grid-tied or off-grid solar setups. Its ability to operate without a battery ensures versatility, making it suitable for areas with frequent power outages or variable grid stability. Designed for easy installation, it is a perfect solution for homes and businesses seeking efficient energy management.
