This hybrid inverter integrates an advanced energy management system capable of handling solar energy input, battery storage, and grid power. It is designed for residential and commercial applications, offering pure sine wave output and multiple protection mechanisms to ensure efficient and safe power delivery. The inverter supports a variety of lithium-ion battery modules with customizable capacities and has a built-in MPPT solar charger. It also features an anti-dust kit and smart battery charging design to optimize battery life in various environmental conditions. With support for both on-grid and off-grid operations, this inverter ensures seamless transition and uninterrupted power supply to essential household or commercial appliances.
| BATTERY | |||||
| MODEL 25.6V100AH 25.6V200AH 48V100AH 48V200AH | |||||
| Normal Charging Voltage | 29.2V | 29.2V | 54.75V | 54.75V | |
| Maximum Charging Current | 100A | 100A | 100A | 100A | |
| Discharge Termination Voltage | 21.6V | 21.6V | 40.5V | 40.5V | |
| Recommended Discharge Termination Voltage | 22.4V | 22.4V | 42V | 42V | |
| Maximum Discharge Current | 100A | 100A | 100A | 100A | |
| Single Cell Charging Overvoltage Protection | 3.8V | 3.8V | 3.8V | 3.8V | |
| Overvoltage Protection For The Whole Battery | 29.2V | 29.2V | 54.75V | 54.75V | |
| Low Voltage Protection For Single Cell Discharge | 2.7V | 2.7V | 2.7V | 2.7V | |
| Low VoltageProtection For Whole Group Discharge | 21.6V | 21.6V | 40.5V | 40.5V | |
| Charge Overcurrent Protection | 102~112A | 102~112A | 102~112A | 102~112A | |
| Discharge Overcurrent Protection | 102~122A | 102~122A | 102~122A | 102~122A | |
| BMS Features | High accuracy cel level voltage,currentmeasuring Over-charge,over-discharge protection Short-circuit protection Self-learning intelligent SOC calculation Cell levelactive equalization Multiple communication type Parallel connect function |
||||
| Working Temperature | -15℃~+55℃ | ||||
| Storage Temperature | -20℃~+50℃ | ||||
| Single Battery Module | Dimension(mm) | 541*480*190 | 541*480*190 | 541*480*190 | 541*480*190 |
| Weight(Kg) | 27KG | 54KG | 54KG | 54KG | |
This hybrid inverter is ideal for homes and small businesses looking to integrate renewable energy into their daily operations. It can be used in solar energy systems to store excess power in lithium batteries and provide uninterrupted power during outages or peak usage times. It is especially suitable for areas with frequent power cuts or grid instability, as it efficiently switches between solar, battery, and grid power. The system is also designed for use in both on-grid and off-grid environments, making it a versatile solution for energy independence and cost savings.
