Versatile LS SPHI Hybrid Solar Inverters with Diesel Generator Compatibility
Product Description
The LS SPHI series hybrid solar inverter is designed to support both on-grid and off-grid systems, offering a flexible solution for residential and small commercial applications. It is equipped with advanced features such as AC and DC coupling, ensuring compatibility with existing solar systems. The inverter's ability to support diesel generator integration and handle unbalanced loads makes it a versatile choice for users seeking reliable energy management. It also features a built-in MPPT controller for maximum solar energy utilization, along with intelligent EMS management for automatic grid switching during blackouts.
| Type | LSRTH5KTLS-ML01 | LSRTH6KTLS-ML01 | LSRTH7K6TLS-ML01 | LSRTH8KTLS-ML01 | LSRTH10KTLS-ML01 |
| PV input | |||||
| Max.DC input power (kW) | 7.5 | 9 | 12 | 12 | 15 |
| No.of MPPTtrackers | 4 | ||||
| MPPT vohage range (M) | 120-500 | ||||
| MAXDC input vohage(V) | 500 | ||||
| MAX.input current(A) | 14 | ||||
| MAX,short circuit current (A) | 22 | ||||
| Batteryinput | |||||
| Nomloal yoltage (V | 48 | ||||
| MAXcharging/discharging current (A | 120/120 | 135/135 | 190/190 | 190/190 | 190/210 |
| Battery voltage range(V) | 40-60 | ||||
| Battery type | Lithium/Lead-acid | ||||
| Chargingstrategyfor LHon battery | Sel-adaption toBMS | ||||
| Type | LSRTH5KTLS-ML01 | LSRTH6KTLS-ML01 | LSRTH7K6TLS-ML01 | LSRTH8KTLS-ML01 | LSRTH10KTLS-ML01 |
| AC output(on-grid) | |||||
| Nominal outputpower output togrid (kVA | 5 | 6 | 7.6 | 8 | 10 |
| MAX.apparent power outputto grid (kVA | 5.5 | 6.6 | 8.4 | 8.8 | 11 |
| Outputvoltage range (V | (110-120/(220-240)split phase,240V single phase | ||||
| Output frequency (Hz) | 60(55 to 65) | ||||
| Nominal AC curren output to grid (A) | 20.8 | 25 | 31.7 | 333 | 41.7 |
| Max,ACcurrentoutput to grid(A) | 22.9 | 27.5 | 34.8 | 36.7 | 45.8 |
| Max.gridpassthroughcument (A) | 100 | ||||
| Output THD | <3% | ||||
| AC output(back-up) | |||||
| Nominal.apparent power(kVA) | 5 | 6 | 7.6 | 8 | 10 |
| Max.apparent power (kVA) | 5.5 | 6.6 | 8.4 | 8.8 | 11 |
| Nominal output voltage L-N/L1-L2(V | 120/240 | ||||
| Nominal output frequency (Hz) | 60 | ||||
| Automatic switchover time(ms) | <20 | ||||
| Output powerfactor | 0.8ending-0,8lagging | ||||
| Output THDu | <2% | ||||
| Protection | |||||
| Grounding detection | Yes | ||||
| Arc faut protecton | Yes | ||||
| Island protection | Yes | ||||
| Battery reverse polarty | Yes | ||||
| nsulationresistor detection | Yes | ||||
| Residual current monitoringunit | Yes | ||||
| Output over currentprotection | Yes | ||||
| Back-up output short protection | Yes | ||||
| Output over voltage protection | Yes | ||||
| Output under voltage protection | Yes | ||||
| General data | |||||
| Mppt efficency | 99.9% | ||||
| Europe effliclency (PV) | 96.5% | ||||
| PV to gridefficiency (PV) | 97.2% | ||||
| Battery to load efficiency | 95.2% | ||||
| PVto battery charing efficiency | 96.1% | ||||
| Grid to battery charing efficiency | 95.0% | ||||
| Output conduit(mm) | 25.4 | ||||
| PV inout condult(mm | 25.4 | ||||
| BAT input condult (mm | 35.4 | ||||
| Operating temperature range(C) | -25~+60 | ||||
| Relative humidty | 0-95% | ||||
| Operating altitude | 0~4,000m(Derating above 2,000m altitude) | ||||
| Ingross protectoo | IP65/NEMA.38 | ||||
| Buil-in breaker | Optiona | ||||
| Weight (kg) | 48kg(50kg withbreaker) | ||||
| Dimensions W*H*D (mm) | 450x820×240 | ||||
| Cooling | FAN cooling | ||||
| Noisoemission (dB | 38 | ||||
| Display | LCD,Touch panel(optinal) | ||||
| Communicationwith BMS/Meter/EMS | RS485,CAN | ||||
| Supported communication intertace | RS485,WLAN,4G(optional | ||||
| Selfoonsumption | <25W | ||||
| Satety | UL1741SA all optons,UL1699B,CSA 22.2 | ||||
| EMO | FQC part 15 class 日 | ||||
| Support dieselgenerator | YES | ||||
| Other data | |||||
| Pek power (off grid) 105%,60s/110%,30s/120%,10s/150%,20ms | |||||
Application
This hybrid solar inverter is ideal for residential homes, small commercial spaces, and areas with intermittent grid supply or those relying on diesel generators. It provides a seamless energy solution, ensuring uninterrupted power supply and the optimal use of renewable energy.
