DH Three-phase Hybrid Inverters The Ideal Choice for Large Grid-tied and Off-grid Systems
Product Description
The DH Three-phase Hybrid Inverter Series (6kW/8kW/10kW/12kW) is a high-efficiency power conversion device designed for medium to large-scale power requirements. This series utilizes advanced power electronics technology to achieve excellent AC/DC and DC/AC conversion efficiency, significantly reducing system energy consumption. Its wide voltage input range allows for compatibility with various battery types and voltages, enhancing system flexibility and adaptability. Additionally, the inverter supports multi-unit parallel operation and system expansion to meet diverse energy needs.
Total 4 Model
| Technicle Specifications | ||||
| Model | HYBRID6KTR-EU | HYBRID8KTR-EU | HYBRID10KTR | HYBRID12KTR |
| Battery | ||||
| Battery Type | LFP/Lead-acid | |||
| Voltage Range(V) | 150~800 | |||
| Max.Operating Current(A) | 50 | |||
| PVInput | ||||
| Max.PVInput Power (W) | 7500 | 12000 | 15000 | 18000 |
| Max.PVInput Voltage (V) | 1100 | |||
| MPPT Voktage Range(V) | 160~1000 | |||
| Start-up Voltage (V) | 150 | |||
| Number of MPPTs | 2/2 | |||
| Max.PVInput Current(A) | 20 | |||
| AC Input and Output (On-grid) | ||||
| Nominal Input/Output Apparaent Power(VA) |
6000 | 8000 | 10000 | 12000 |
| Nominal Input/Output Voltage (V) | 380/400 | |||
| Nomina Grid Frequency(Hz) | 50/60 | |||
| Max.Input/Output Current(A) | 13.6 | 18.2 | 22.7 | 27.3 |
| THD | <3% | |||
| Power Factor | 0.8Lead~0.8 Lag | |||
| AC Input and Output (Off-gnd) | ||||
| Nomina AC Apparaent Power (VA) | 6000 | 8000 | 10000 | 12000 |
| Peak Output Apparent Power (VA) | 1,200,010 | 1,600,000 | 1,600,010 | 1,600,010 |
| Nominal AC Voltage(V) | 380/400 | |||
| Nominal Grid Frequency(Hz) | 50/60 | |||
| Max.Output Current(A) | 10 | 13.3 | 16.7 | 20 |
| THD | <3% | |||
| Switch time(ms) | 10 | |||
| Efficiency | ||||
| Max.Efficiency | 98.5% | |||
| MPPT Efficiency | >99% | |||
| Protection | ||||
| Technical Support | Supported Anti-islanding Protection,Reverse Connection Protection,DC Switch Insulation Impedance,AC Overcurrent/Overvoltage Protection,AC Short Currentprotection |
|||
| Surge Protection | DC TYPE IⅡ,AC TYPE Ⅱ | |||
| Genera | ||||
| Dimension W*H*D(mm) | 524*440*220 | |||
| Weight (Kg) | 25 | |||
| Operating Temperature(℃) | -20~60 | |||
| Relative Humidity | 0~95%,no condensation | |||
| Permissible Altitude(m) | 4000(>2000m derating) | |||
| IP Rating | IP66 | |||
| Noize (dB) | <35 | |||
| Communication Interface | RS485/CAN,WIF/4G/LAN,Bluetooth(Optional) | |||
| Display | LCD | |||
| Safety EMC/Certification | EN 61000-6-1/3,IEC62109-1,IEC62109-2 | |||
Application
The DH Three-phase Hybrid Inverter is widely used in industrial, commercial, and large-scale residential projects. Its high-efficiency energy conversion and flexible scalability make it an ideal choice for large grid-tied and off-grid systems. Whether serving as the main power source in industrial power systems or as a backup power supply in commercial buildings, this inverter provides stable and reliable energy, particularly in scenarios requiring diversified power inputs and high reliability.
