The M5-20ft-1MW/2MWh energy storage system is a robust, high-capacity solution designed for grid-scale and industrial energy applications. With a system capacity of 2069.76 kWh and dual PCS units delivering 1 MW power output, this containerized system ensures high performance and reliability for demanding energy needs. The advanced air cooling system, coupled with a wide working temperature range (-20℃ to 50℃), allows the system to operate efficiently in diverse climates. Certified under global standards, including IEC and UL, and equipped with perfluoro fire suppression technology, the M5 system prioritizes safety, longevity, and operational stability. Its modular 20-foot container design offers easy deployment and scalability, making it a perfect fit for large-scale energy projects.
| Battery Data | M5-20ft-1MW/2MWh | ||
| System Capacity (kWh) 2069.76 | |||
| DC Voltage range (Vdc) | 638~781(single string) | ||
| Life Cycle >7000 | |||
| Depth of Discharge | 98%(single string) | ||
| General Data | |||
| Dimension(W*D*H mm) | 6058*2438*2896 | ||
| Weight(tons) | 28 | ||
| Protection Class | IP55 | ||
| Altitude(m) | ≤4000 | ||
| Humidity (RH) | 5%~95% | ||
| Cooling System | Air Cooling | ||
| Cooling System Consumption (kW) 40 | |||
| Aux.Power Consumption (continuous/peak,incl HVAC)(kW) 30 | |||
| Working Temperature Range(C) | -20~50* | ||
| Fire Extinguishing | Perfluoro | ||
| Communication Type | RS485CANEthernet | ||
| Operation Logic Peak Shaving/Energy Shifting/Self-Consumption | |||
| Certification | UN38.3/UN 3480/IEC62619/IEC62040-1/CE/UKCA(EMC/RED)/VDE2510-50/UL1973/UL9540A CE LVD/ IEC 62477/ CE EMC/ IEC 61000/ EN 50549-1:2019/ G99/ AS4777 |
||
| Anti-Corrosion | C3H(C5 Optional) | ||
| PCS DC/AC Data On-grid Mode | |||
| PCS number | 2 | ||
| Rated AC Power(kW) | 500 | ||
| Rated AC Output Voltage(Vac) | 400±15% | ||
| Rated AC Output Frequency (Hz) | 60±25 | ||
| Max AC Current (A) | 0~720 | ||
| Overload Capacity | 125%~150%@200ms | ||
| AC PF | 0.8~1 leading or lagging | ||
| CEC Efficiency@0.5C-rate | 97% | ||
| IsolationType | Non isolated type | ||
Grid Balancing and Peak Load Management:
The M5 system is ideal for utility providers seeking efficient grid stabilization. Its rapid response capabilities and 97% efficiency ensure optimized energy shifting and peak shaving, addressing fluctuations in energy demand and supply.
Industrial Energy Independence:
For large industrial operations, this system provides a reliable power source, reducing dependence on grid electricity. With a durable IP55 protection class and anti-corrosion options (C3H/C5), it is suited for heavy-duty environments, including remote mining or manufacturing sites.
Renewable Energy Integration:
Seamlessly integrates with renewable energy sources like solar and wind, storing excess energy during peak production and dispatching it during demand surges, enhancing the overall efficiency and reliability of renewable energy systems.
Emergency and Backup Power:
Equipped with robust fire suppression and advanced cooling, the M5 system ensures uninterrupted power supply for critical infrastructures, including hospitals, data centers, and telecom networks, even in extreme conditions.
The M5-20ft-1MW/2MWh energy storage system is a versatile, future-proof solution that combines high capacity, safety, and adaptability to meet the complex demands of modern energy systems.
