Product Description:
This Commercial & Industrial Energy Storage System (ESS) offers a standardized, modular design aimed at high energy efficiency and long-lasting operation. With a nominal capacity ranging from 114.72kWh to 186.42kWh, the ESS uses LiFePO4 battery technology to ensure durability and safety. Each unit comes with advanced GK-developed BMS tested over 10 years for reliable performance, built-in high-performance PCS to ensure safety, and a lifespan of over 6500 cycles. The ESS features IP20 waterproof protection, making it ideal for various commercial environments. Its scalable architecture allows seamless integration with existing energy systems, supporting floor-standing installations.
| Nominal Capacity | 114.72kWh | 143.4kWh | 172.08kWh | 186.42kWh |
| Cell Matching | 128S1P | 160S1P | 192S1P | 208S1P |
| Nominal Voltage | 409.6V | 512V | 614.4V | 665.6V |
| Working Voltage Range | 176-233.6V | 264-350V | 440-584V | 582.4-748.8V |
| Weight | 1165kgs/2568 Ibs | 1370kgs/3020 Ibs | 1624.5kgs /3581 Ibs | 1844.5kgs/4066 Ibs |
| Dimension(W*D*H) | 1200*1000*2200mm/47.2*39.4*81.4 in | |||
| Batter Type | LiFePO4 Battery | |||
| Nominal Working Current | 150A | |||
| Communication Port | CAN/RS485 | |||
| Working Temperature Range | Charge:0-45℃/Discharge:-10-50℃ | |||
| Waterproof | IP20 | |||
| Installation Method | Floor-standing | |||
| Cycle Life | 6500 | |||
| Peak Charge/Discharge Current(@25℃,5S) |
200A | |||
| Discharge Rate of Module | ≤3.5%/month/@25℃ | |||
Application:
This ESS is designed for use in commercial and industrial environments where energy storage is crucial. Ideal for large-scale energy management, including peak shaving, load shifting, and backup power, it is suitable for applications such as:
