215kWh High-Efficiency Industrial Charger for Large-Scale Applications
Product Description:
This industrial-grade energy storage system is designed for large-scale applications, featuring a high-efficiency 215kWh lithium iron phosphate (LiFePO₄) battery pack. The system supports flexible parallel configuration, allowing up to 10 units for expansion, providing scalable energy storage solutions. The system integrates IP55 protection, ensuring reliability in various outdoor and industrial environments. It also features full liquid cooling to improve environmental adaptability and extend the lifespan of the battery pack. This energy storage solution is perfect for managing power loads, demand management, and emergency backup.
| Productcharacteristics | |||||||
| Intelligentand friendly | |||||||
| 380Vis directly connected to the grid,effectively reducing construction costs Cell health monitoring,abnormal cell arly warning |
|||||||
| Cooperate with self-developed cloud platform andAPP to realize monitoring and management anytime and anywhere Efficient and flexible |
|||||||
| It supportsup to 10 parallelmachines and can be flexibly configured on demand for easy expansion Configure photovoltaic inverterand STS switch as required to achieve full coverage of the scene Integrated design,pre-assembly and shipment,shorten the delivery cycle,reduce engineering costs |
|||||||
| Safe and reliable | |||||||
| IP55 protection grade,meet the requirementsof outdoor operation PACK level active fire protection for safer system |
|||||||
| Battery system,PCS fulliquid cooling design,more environmental adaptability | |||||||
| Application field | |||||||
| Industrial park,industrial and commercial photovoltaic power station,optical storage and charging station,distribution station area,microgrid,data center and other occasions |
|||||||
| Charge Controller | |||||||
| 10PACK 1P48S 43kWh |
2#PACK | 5#PACK | |||||
| FU | |||||||
| FU | |||||||
| AC Side |
Rated AO Power | 100kVA | |||||
| AC overoad Capacity | 110kVA | ||||||
| Connection Mode | Three-Phase Four-Wire System | ||||||
| On-grid AC Votage | 380/400V(-20%~15%) | ||||||
| On-grid Frequency | 50/60Hz(-2.5-2.5) | ||||||
| Total HarmonicDistortion | <3% | ||||||
| Power Factor | -0.99%~+0.99 | ||||||
| Max.Conversion Efficiency | 98.5% | ||||||
| DC Side |
BatteryType | Lithiun ironphosphate 3.2V/280Ah | |||||
| CellConfigurations | 1P240S | ||||||
| Rated Capacity | 280Ah | ||||||
| Rated Energy | 215kWh | ||||||
| Rated Voltage | 768V | ||||||
| Voltage Range | 672~864V | ||||||
| Standard Charge/Discharge Current | 140A/140A | ||||||
| Cooling | Liquid cooling | ||||||
| Coolant | Ethylene glycol:aqueous solution(50%:50%) | ||||||
| Life Cycles | 8000 | ||||||
| Fire Suppression | NOVEC 1230/FM200 | ||||||
| Detector | Smoke,heat &flammable gas detectors | ||||||
| System Parameter |
Efficlengy | 2.88% | |||||
| Dimensions | 1300×1350×2050(W×D×H,mm) | ||||||
| Weight | ≤2.7t | ||||||
| Battery Charge/DischargeOperating Temperature | 0℃-55℃/-20*C-55℃ | ||||||
| Relative Humidity | 0~95%(no condensing | ||||||
| Standard Altitude | <2000m(>2000m,derating) | ||||||
| Noise | <75dB | ||||||
| Anti-corrosion | C3/C4 | ||||||
| IP Rating | IP55 | ||||||
| System Communication Interface | Ethernet/4G/RS485 | ||||||
| ExternalSystem Communication Protocol | Modbus RTU,Modbus TCP,CAN2.0B,IEC61850 | ||||||
| Compliance | GB/T36276-2018,IEC62619,UL1971,UL9540A | ||||||
| Operation Mode |
Cut Peaks and Fill Valleys | Yes | |||||
| Demand Management | Yes | ||||||
| PluripotentSynergy | Yes | ||||||
| Dynamic Capacity Increase | Yes | ||||||
| Emergency Backup | Yes | ||||||
| Anti-Befux | Yes | ||||||
| Remarks:Specifications are subject to change without notice;Speclal voltage and power requirements can be customized designed | |||||||
Application:
Ideal for industrial parks, commercial photovoltaic power stations, data centers, and microgrids. The system can be deployed in optical storage and charging stations, distribution areas, and public infrastructure requiring high-power storage solutions. The reliable and modular design makes it easy to scale energy storage to meet growing energy demands.
