The OL3 Liquid-Cooled Outdoor Cabinet L3 (105kW/233kWh) is the latest in advanced energy storage solutions, specifically designed for environments where space is at a premium, but high energy capacity is required. This cabinet features high-efficiency Lithium Iron Phosphate (LFP) batteries, with 280Ah large-capacity cells capable of delivering up to 8000 cycles, ensuring a long and stable power supply. What sets the L3 apart is its compact design, allowing it to be deployed easily in various spatial environments while still delivering powerful performance. The advanced liquid cooling system ensures optimal temperature management, enhancing the overall performance and lifespan of the battery system. Additionally, the cabinet is engineered to operate efficiently under harsh conditions, with a protection level of IP54 and a corrosion protection option, making it a robust choice for critical applications.
| Technicle Specifications | |
| Model DZ105233L3 | |
| DC Side | |
| Rated Battery Capacity | 233kWh |
| Rated Battery Voltage | 832V |
| Battery Voltage Range | 780V-936V |
| Battery Type | LFP |
| Cell Capacity | 280Ah |
| Cyde Life | 8000 cydes (0.5C,5%~95%DOD,70%SOH) |
| Standard Charge/Discharge Current | 0.5C |
| Series-Parallel Connection Method | 1P52S (5set) |
| Module Cooling Method | Liquid-cooling |
| AC Side | |
| Rated AC Power | 105kW |
| Maximum Efficiency | 98.50% |
| Rated AC Voltage | 230/400V |
| Grid Voltage Range | 320-460V |
| Rated AC Frequency | 50/60Hz |
| Total Harmonic Distortion of Current THDI | <3%(RatedPower) |
| Power Factor | -1 Leading-+1 Lagging |
| Total Harmonic Distortion of Voltage THDI | <3%(Linear Load) |
| PCS Cooling Method | Air cooling |
| System Parameter | |
| Energy Cyde Efficiency | ≥90% |
| Protection Level | IP54 |
| Corrosion Protection Level | C3 by default,C4/C5optional |
| lsolation Method | Non-isolated (lsolation transformer optional) |
| Relative Humidity | 0~95%(No condensation) |
| Operating Temperature | -30℃~55℃(derating above 45℃) |
| Cooling Method | Liquid Cooling |
| Altitude | <4000m(derating over 2000m) |
| BMS Communication | CAN2.0b |
| EMSCommunication | 4G/CAN/RS485 |
| Dimensions (W*D*H) | 1000 mm×1300 mm×2320 mm |
| Weight(Approx.) | 2200kg |
| Annual Degradation Rate | <3% |
| Warranty | 5 years |
The OL3 Liquid-Cooled Outdoor Cabinet L3 is ideal for urban and industrial settings where space is limited, but reliable and high-capacity energy storage is essential. Its compact size and advanced cooling technology make it suitable for deployment in dense urban areas, industrial parks, or even remote installations where conditions can be challenging. The cabinet’s robust design, coupled with its high efficiency and long lifespan, makes it perfect for critical infrastructure, renewable energy integration, and other high-demand energy applications where minimal space and maximum performance are required.
