13kWh 15kWh DB Stackable All-in-One Portable Battery Series The Perfect Fit for Your Energy Needs
Product Description
The DB Stackable All-in-One Portable Battery Series (13kWh, 15kWh) is designed to offer a versatile and scalable energy storage solution that meets the diverse demands of modern energy needs. This series combines high energy storage capacity with portability, making it ideal for both residential and commercial applications that require flexible energy solutions. With a storage range from 5120Wh to 20480Wh, these batteries cater to various energy requirements, allowing users to easily expand their capacity as needed. The integrated design ensures efficient energy conversion, with a rated input/output apparent power of 5000VA and a maximum output current of 21.7A. Additionally, the stackable feature allows for easy expansion, making this series adaptable to changing energy needs over time.
Total 4 Model
| Technical specifications |
| mode |
DDYTJKY51100-5k-W |
DDYTJKY51200-5k-W |
DDYTJKY51300-5k-W |
DDYTJKY51400-5k-W |
| Battery |
|
|
| Cell Chemistry |
LFP |
| Nominal Energy (Wh) |
5120 |
10240 |
15360 |
20480 |
| Nominal Capacity(Ah) |
100 |
200 |
200 |
200 |
| Nominal Votage(V) |
51.2 |
| Working VoltageRange (VDC) 44.8~58.4 |
| Max.Charge/Discharge Current (A) 100A |
| BMS Communication CAN2.0/RS485 |
| PVInput |
| Max.PVInput Power (W) 7500 |
| Max.PVInput Voltage(V) 600 |
| MPPT Vottage Range(V) 100~550 |
| Start-up Voltage (V) 125 |
| Number of MPPTs 2 |
| Number of PV Strings per MPPT 1/1 |
| Max.PVInputCurrent(A) 20 |
| AC loput and Output (On-grid) |
| Nominal Input/Output Apparaent Power (VA) 5000 |
| Nominal Input/Output Voltage (V) 230 |
| Nominal Grid Frequency(Hz) 50/60 |
| Max.Output Current(A) 21.7 |
| THD <3% |
| Power Factor 0.8 leading~0.8 lagging |
| Switch time(ms) 10 |
| Grid Connection Single Phase |
| General Ihformation |
| Dimension [H*W*D](mm) |
680*400*430 |
680*400*592 |
680*400*754 |
680*400*916 |
| Packing |
Pack separatelyinverters and bases do not require hazardous packaging:
hazardous packaging for batteries,one battery package per cardboardbox. |
| Weight (kg) |
63 |
| Packing Weight (kg) |
75 |
| Permissible Altitude (m) |
4000(>2000 derating) |
| Dispaly Screen |
LCD/LED |
| IP Rating |
IP65 |
| Working Temperature(℃) |
-20~60 |
| Relative Humidity |
0~95%,no condensation |
| Cyce Life |
6000 cydes |
| Warranty |
5 years |
| Installation Type |
Portable |
| Certification |
IEC62619/EN61000-6-1/EN61000-3/RoHS/UN38.3 |
Application
The DB Stackable All-in-One Portable Battery Series is perfect for customers seeking a portable yet powerful energy storage solution that can grow with their energy demands. The stackable design is particularly suited for environments where space-saving is crucial, such as urban residences or mobile power setups. Whether for use in off-grid applications, as a backup power source, or in portable energy systems, this series offers the flexibility to adjust storage capacity according to current and future needs. Its robust construction and high IP65 rating make it suitable for outdoor and challenging environments, providing reliable energy storage in all conditions.
Shipping Methods
Supports global air and sea shipping
